| Engine Type | Liquid-cooled, 4-stroke V-Twin,SOHC,8 Valves |
| Displacement | 1,700 cm³ |
| Bore And Stroke | 102 mm x 104 mm |
| Compression Ratio | 9.5:1 |
| Performance: | |
| a) Maximum Power |
54 kW { 73 PS}/ 5,000 rpm |
| b) Maximum Torque | 136 N.m { 13.9 kgf.m}/ 2,750 rpm |
| Fuel System | Fuel injection: ø42 mm x 2 |
| Iginition | Digital |
| Starting | Electric |
| Lubrication | Forced lubrication, semi-dry sump |
DRIVE TRAIN
| Transmission | 6-speed, Return |
|
Gear ratios: Primary reduction ratio |
1.515 (50/33) |
| 1st | 2.933 (44/15) |
| 2nd | 1.900 (38/20) |
| 3rd | 1.407 (38/27) |
| 4th | 1.143 (32/28) |
| 5th | 0.967 (29/30) |
| 6th | 0.806 (29/36) |
| Final reduction ratio | 2.250 (72/32) |
|
Clutch Final Drive |
Wet multi-disc, manual Belt |
FRAME /TYRE
| Type | Double-cradle,steel |
| Caster (Trail) | 177 mm |
| Tyre: | |
| a) Front | 130/90B-16M/C 67H |
| b) Rear | 170/70B- 16 M/C 76H |
SUSPENSION
| Front Suspension |
|
|
| Rear Suspension | Swingarm with twin air-assisted adjustable shocks. Rebound dampling: 4 way | |
| BRAKES | ||
|
Front Type Caliper |
Dual 300 mm discs Dual 4-piston |
|
|
Rear Type Caliper |
Single 300 mm disc Twin-piston |
DIMENSION
| Overall length | 2,465 mm |
| Overall width | 1,005 mm |
| Overall height | 1,065 mm |
| Wheelbase | 1,645mm |
| Ground clearance | 135 mm |
| Seat height | 680 mm |
| Curb mass | 254 Kg |
| Fuel capacity | 20 liters |
*Actual model may vary in detail from image shown and specifications are subject to change without prior notice.
