Engine Type | Liquid-cooled, 4-stroke In-Line Four,DOHC,16 Valves |
Displacement | 1441 cm³ |
Bore And Stroke | 84.0 mm x 65.0 mm |
Compression Ratio | 12.3:1 |
Performance: | |
a) Maximum Power |
147.2 kW { 200 PS}/ 10,000 rpm 154.5 kW { 210 PS}/ 10,000 rpm (with RAM Air) |
b) Maximum Torque | 158.2 N.m { 16.1 kgf.m}/ 7,500 rpm |
Fuel System | Fuel injection: ø44 mm x 4 (Mikuni) |
Iginition | Digital |
Starting | Electric |
Lubrication | Forced lubrication (wet sump with oil cooler) |
DRIVE TRAIN
Transmission | 6-speed, Return |
Gear ratios: | |
1st | 2.611 (47/18) |
2nd | 1.947 (37/19) |
3rd | 1.545 (34/22) |
4th | 1.333 (32/24) |
5th | 1.154 (30/26) |
6th | 1.036 (29/28) |
Final reduction ratio | 2.471 (42/17) |
Clutch | Wet multi-disc, manual |
FRAME /TYRE
Type | Monocoque,aluminium |
Caster (rake) | 23° degrees |
Tyre: | |
a) Front | 120/70ZR-17 M/C (58W) |
b) Rear | 190/50ZR - 17 M/C (73W) |
SUSPENSION
Front Suspension |
|
|
Rear Suspension | Bottom-Link Uni-Trak,Ohlins TTX39 rear shock with piggyback reservior and preload adjuster,compression and rebound dampling and spring preload adjustability | |
BRAKES | ||
Front Type Caliper |
Dual semi-floating ø310 mm Brembo discs Dual radial-mount,Brembo M50 monoblac,opposed 4-piston |
|
Rear Type Caliper |
Single ø250 mm petal disc. Opposed. 2-piston |
DIMENSION
Overall length | 2,170 mm |
Overall width | 770 mm |
Overall height | 1,170 mm |
Wheelbase | 1,480mm |
Ground clearance | 125 mm |
Seat height | 800 mm |
Curb mass | 269 Kg |
Fuel capacity | 22 liters |
*Actual model may vary in detail from image shown and specifications are subject to change without prior notice.
